MAX4678EUE

2Ω ，四路， SPST ， CMOS模拟开关 2з, Quad, SPST, CMOS Analog Switches

General Description

The MAX4677/MAX4678/MAX4679 quad analog switch es feature 1.6Ω max on-resistance RON when operating from a dual ±5V supply. RON is matched between channels to 0.3Ω max and is flat 0.4Ω max over the specified signal range. Each switch can handle Rail-to Rail® analog signals. Off-leakage current is 0.1nA at +25°C. These switches are ideal in low-distortion applications and are the preferred solution over mechanical relays in automated test equipment. They have low power requirements, require less board space, and are more reliable than mechanical relays.

Features

♦ On-Resistance 1.6Ω max

♦ On-Resistance Flatness 0.4Ω max

♦ On-Resistance Matching 0.3Ω max

♦ Dual ±2.7V to ±5.5V or Single +2.7V to +11V Supply Range

♦ TTL/CMOS-Logic Compatible

♦ Crosstalk -84dB at 1MHz

♦ Off-Isolation -65dB at 1MHz

♦ -3dB Bandwidth: 66MHz

♦ Rail-to-Rail Signal Range
