M74HCT367M1R

具有三态输出的非反相HEX BUS BUFFER HEX BUS BUFFER WITH 3 STATE OUTPUT NON INVERTING

DESCRIPTION

The M74HCT367 is an high speed CMOS HEX BUS BUFFER 3-STATE OUTPUTS fabricated with silicon gate C2MOS technology.

■ HIGH SPEED:

  tPD = 14ns TYP. at VCC = 4.5V

■ LOW POWER DISSIPATION:

  ICC = 4µAMAX. at TA=25°C

■ COMPATIBLE WITH TTL OUTPUTS :

   VIH = 2V MIN. VIL = 0.8V MAX

■ SYMMETRICAL OUTPUT IMPEDANCE:

   |IOH| = IOL = 6mA MIN

■ BALANCED PROPAGATION DELAYS:

   tPLH = tPHL

■ PIN AND FUNCTION COMPATIBLE WITH 74 SERIES 367
