DIODES INC. MMBD4448H-7-F 二极管 小信号, 排列, 单, 80 V, 150 mA, 1.25 V, 4 ns, 4 A
DIODE GEN PURP 80V 250MA SOT23-3
得捷:
DIODE GEN PURP 80V 250MA SOT23-3
立创商城:
100V 500mA 4ns
e络盟:
DIODES INC. MMBD4448H-7-F 二极管 小信号, 排列, 单, 80 V, 150 mA, 1.25 V, 4 ns, 4 A
艾睿:
Converting from AC to DC is simple when using a switching diode MMBD4448H-7-F rectifier from Diodes Zetex. Its maximum power dissipation is 350 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This rectifier has a minimum operating temperature of -65 °C and a maximum of 150 °C. It is made in a single configuration. Its peak non-repetitive surge current is 4 A, while its maximum continuous forward current is 0.25 A.
Allied Electronics:
Diode Switching 0.25A 80V SOT23
富昌:
MMBD4448H 系列 4 A 80 V 350 mW 表面贴装 开关二极管 - SOT-23
Chip1Stop:
Diode Switching 80V 0.25A 3-Pin SOT-23 T/R
Verical:
Rectifier Diode Small Signal Switching 80V 0.25A 4ns 3-Pin SOT-23 T/R
Win Source:
DIODE GEN PURP 80V 250MA SOT23-3
额定电压DC 80.0 V
额定电流 250 mA
电容 3.50 pF
额定功率 350 mW
输出电流 ≤250 mA
针脚数 3
正向电压 1.25V @150mA
极性 Standard
耗散功率 350 mW
反向恢复时间 4 ns
正向电流 150 mA
最大正向浪涌电流(Ifsm) 4 A
正向电压Max 1.25 V
正向电流Max 0.25 A
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 350 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
宽度 1.4 mm
封装 SOT-23-3
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MMBD4448H-7-F Diodes 美台 | 当前型号 | 当前型号 |
MMBD4448H-7 美台 | 类似代替 | MMBD4448H-7-F和MMBD4448H-7的区别 |
