Diode Zener Single 30V 5% 350mW 3Pin SOT-23 T/R
- 齐纳 ±5% 表面贴装型 SOT-23-3
得捷:
DIODE ZENER 30V 350MW SOT23-3
立创商城:
30V 350mW
艾睿:
This MMBZ5256B-7-F zener diode from Diodes Zetex is perfect for your circuit requiring a diode to operate in the reverse-breakdown region. Its test current is 4.2 mA. Its maximum leakage current is 0.1 μA. Its maximum power dissipation is 350 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This zener diode has an operating temperature range of -65 °C to 150 °C. This zener device has a nominal voltage of 30 V and a voltage tolerance of 5%. It is made in a single configuration.
安富利:
Diode Zener Single 30V 5% 350mW 3-Pin SOT-23 T/R
Chip1Stop:
Diode Zener Single 30V 5% 350mW 3-Pin SOT-23 T/R
Verical:
Diode Zener Single 30V 5% 350mW Automotive 3-Pin SOT-23 T/R
Win Source:
DIODE ZENER 30V 350MW SOT23-3
额定电压DC 30.0 V
容差 ±5 %
额定功率 350 mW
正向电压 900mV @10mA
耗散功率 350 mW
测试电流 4.2 mA
稳压值 30 V
正向电压Max 900mV @10mA
额定功率Max 350 mW
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 350 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 3.05 mm
宽度 1.4 mm
高度 0.98 mm
封装 SOT-23-3
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MMBZ5256B-7-F Diodes 美台 | 当前型号 | 当前型号 |
MMBZ5256B-7 美台 | 完全替代 | MMBZ5256B-7-F和MMBZ5256B-7的区别 |
MMBZ5256BLT1 乐山无线电 | 功能相似 | MMBZ5256B-7-F和MMBZ5256BLT1的区别 |
