MAX14878AWE+

总线, CAN, 隔离型, CAN, 1, 1, 1.71 V, 5.5 V, WSOIC

This family of high-speed transceivers integrates up to 5kV integrated galvanic isolation with fault protection and ±15kV Human Body Model HBM ESD to increase uptime in harsh and noisy environments. They operate up to the maximum high-speed CAN data rate of 1Mbps and feature ±54V fault protection on receiver inputs. Available in industry-compatible pin-outs, the transceivers are packaged in a wide-body 16-pin SOIC package with 8mm of creepage and clearance and operate over the -40°C to +125°C temperature range.

.

Up to 5kV integrated galvanic isolation

.

UL1577 certified

.

±54V fault protection

.

±15kV HBM ESD

.

Robust communications increase uptime

.

Building Automation; HVAC; Industrial Controls; Switching Gear
