Diode Zener Single 8.7V 5% 350mW 3Pin SOT-23 T/R
- 齐纳 ±5% 表面贴装型 SOT-23-3
得捷:
DIODE ZENER 8.7V 350MW SOT23-3
立创商城:
8.7V 350mW
艾睿:
Check out this perfect MMBZ5238B-7-F zener diode from Diodes Zetex for operating in the reverse breakdown region. Its maximum leakage current is 3 μA. Its test current is 20 mA. Its maximum power dissipation is 350 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It is made in a single configuration. This zener diode has an operating temperature range of -65 °C to 150 °C. This zener device has a nominal voltage of 8.7 V and a voltage tolerance of 5%.
安富利:
Diode Zener Single 8.7V 5% 350mW 3-Pin SOT-23 T/R
Chip1Stop:
Diode Zener Single 8.7V 5% 350mW 3-Pin SOT-23 T/R
Verical:
Diode Zener Single 8.7V 5% 350mW Automotive 3-Pin SOT-23 T/R
Win Source:
DIODE ZENER 8.7V 350MW SOT23-3
额定电压DC 8.70 V
电容 35 pF
容差 ±5 %
额定功率 350 mW
正向电压 900mV @10mA
耗散功率 350 mW
测试电流 20 mA
稳压值 8.7 V
正向电压Max 900mV @10mA
额定功率Max 350 mW
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 350 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 3.05 mm
宽度 1.4 mm
高度 1 mm
封装 SOT-23-3
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MMBZ5238B-7-F Diodes 美台 | 当前型号 | 当前型号 |
MMBZ5238B-7 美台 | 完全替代 | MMBZ5238B-7-F和MMBZ5238B-7的区别 |
CMPZ5238B TR Central Semiconductor | 类似代替 | MMBZ5238B-7-F和CMPZ5238B TR的区别 |
SZMMBZ5238BLT1G 安森美 | 功能相似 | MMBZ5238B-7-F和SZMMBZ5238BLT1G的区别 |
