OPA2171AIDR

TEXAS INSTRUMENTS  OPA2171AIDR  运算放大器, 双路, 3 MHz, 2个放大器, 1.5 V/µs, 2.7V 至 36V, SOIC, 8 引脚

The is a low power RRO general purpose Operational Amplifier with the ability to operate on supplies ranging from 2.7 ±1.35V to 36V ±18V. This amplifier offers low offset, drift and bandwidth with low quiescent current. Unlike most operational amplifiers, which are specified at only one supply voltage, the OPAx171 family is specified from 2.7 to 36V. Input signals beyond the supply rails do not cause phase reversal. The op-amp is stable with capacitive loads up to 300pF. The input can operate 100mV below the negative rail and within 2V of the top rail during normal operation. This device can operate with full rail-to-rail input 100mV beyond the top rail, but with reduced performance within 2V of the top rail.

.

14nV/√Hz Low noise

.

RFI filtered inputs

.

Input range includes the negative supply

.

Input range operates to positive supply

.

Rail-to-rail output

.

475µA per Amplifier low quiescent current

.

120dB High CMRR

.

8pA Maximum low bias current

.

Green product and no Sb/Br

This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
