OPA4180IPW

TEXAS INSTRUMENTS  OPA4180IPW  运算放大器, 四路, 2 MHz, 4个放大器, 0.8 V/µs, 4V 至 36V, TSSOP, 14 引脚

The is a quad low noise Operational Amplifier uses zero-drift techniques to simultaneously provide low offset voltage 75µV, near zero-drift over time and temperature. This miniature, high-precision, low quiescent current amplifier offers high input impedance and rail-to-rail output swing within 18mV of the rails. The input common-mode range includes the negative rail.

.

RFI filtered inputs

.

Excellent DC precision - 126dB PSRR, 114dB CMRR and 120dB open-loop gain AOL

.

0.1µV/°C Zero-drift

.

10nV/√Hz Low noise

.

525µA Maximum quiescent current

.

250pA Typical low bias current

.

Green product and no Sb/Br
