OA2MPA22Q

STMICROELECTRONICS  OA2MPA22Q  运算放大器, 双路, 150 kHz, 2个放大器, 0.06 V/µs, 1.5V 至 5.5V, DFN, 8 引脚

The is a high precision low-power dual CMOS Operational Amplifier offers low-voltage operation, rail-to-rail input and output and excellent precision Vio lower than 200µV at 25°C. This low power op amp benefit from STMicroelectronics 5V CMOS technology and offer an excellent speed/power consumption ratio 150kHz typical gain bandwidth while consuming less than 14µA at 5V. It is suitable for wearable, fitness and healthcare applications.

.

Ultralow input bias current

.

High precision without calibration

.

Energy saving

.

Guaranteed operation on low-voltage battery

.

200µV Maximum low offset voltage

.

10µA at 5V Low power consumption

.

1pA Typical low input bias current

.

4kV HBM High tolerance to ESD
