OPA172IDCKT

TEXAS INSTRUMENTS  OPA172IDCKT  运算放大器, 单路, 10 MHz, 1个放大器, 10 V/µs, 4.5V 至 36V, ± 2.25V 至 ± 18V, SC-70, 5 引脚

The is a single low-noise Operational Amplifier for use with precision integrators. This latest addition of high-voltage CMOS operational amplifier provide a family of bandwidth, noise and power options to meet the needs of a wide variety of applications. This device also offers wide bandwidth, fast slew rate and high output current drive capability. The single version has identical specifications for maximum design flexibility. Input signals beyond the supply rails do not cause phase reversal. The input can operate 100mV below the negative rail and within 2V of the top rail during normal operation.

.

EMI and RFI filtered inputs

.

Input range includes the negative supply

.

Input range operates to positive supply

.

±0.2mV Low offset voltage

.

±0.3µV/°C Low offset drift

.

±8pA Low input bias current

.

1.6mA/amplifier Low quiescent current

.

7nV/√Hz Low noise

.

120dB High common-mode rejection

.

Green product and no Sb/Br
