零偏移运算放大器,OPA 系列### 运算放大器,Texas Instruments
零偏移,OPA 系列
得捷:
IC OPAMP ZERO-DRIFT 1 CIRC 8SOIC
欧时:
### 零偏移运算放大器,OPA 系列### 运算放大器,Texas Instruments
立创商城:
OPA734AID
德州仪器TI:
Single 0.05-uV/degC max single-supply CMOS op amp, zero-drift series with shutdown
贸泽:
精密放大器 0.05uV/degC Single- Supply CMOS
艾睿:
Do you need an electronic device to amplify audio signals in two channels? Then zero drift amplifier OPA734AID differential amplifier from Texas Instruments is perfect for you! It has a CMOS|rail to rail output. Its typical dual supply voltage is ±3|±5 V, with a minimum of ±1.35 V and maximum of ±6 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device uses one or two power supplies. It has a single channel per chip.
安富利:
OP Amp Single GP R-R O/P ±6V/12V 8-Pin SOIC Tube
Verical:
SP Amp Zero Drift Amplifier Single R-R O/P ±6V/12V 8-Pin SOIC Tube
Win Source:
IC OPAMP CHOPPER 1.6MHZ 8SOIC
供电电流 600 µA
电路数 1
通道数 1
共模抑制比 115 dB
输入补偿漂移 10.0 nV/K
带宽 1.60 MHz
转换速率 1.50 V/μs
增益频宽积 1.6 MHz
输入补偿电压 1 µV
输入偏置电流 100 pA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 1.6 MHz
共模抑制比Min 115 dB
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 4.9 mm
宽度 3.91 mm
高度 1.58 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
OPA734AID TI 德州仪器 | 当前型号 | 当前型号 |
OPA734AIDR 德州仪器 | 完全替代 | OPA734AID和OPA734AIDR的区别 |
OPA734AIDG4 德州仪器 | 类似代替 | OPA734AID和OPA734AIDG4的区别 |
OPA734AIDRG4 德州仪器 | 类似代替 | OPA734AID和OPA734AIDRG4的区别 |
