Difet® 双路精密运算放大器 8-PDIP
The configuration of this general purpose amplifier OP amp from Texas Instruments allows it to take on a variety of different behaviors and characteristics with external components such as resistors, capacitors and inductors. Its typical dual supply voltage is ±15 V, with a minimum of ±4.5 V and maximum of ±18 V. This op amp has a temperature range of -25 °C to 85 °C. This device uses dual power supplies. This device utilizes bifet technology. It has 2 channels per chip.
供电电流 4.5 mA
电路数 2
通道数 2
共模抑制比 80 dB
输入补偿漂移 3.00 µV/K
带宽 4.5 MHz
转换速率 18.0 V/μs
增益频宽积 4.5 MHz
过温保护 No
输入补偿电压 100 µV
输入偏置电流 4 pA
工作温度Max 85 ℃
工作温度Min -25 ℃
共模抑制比Min 80 dB
电源电压Max 36 V
电源电压Min 9 V
安装方式 Through Hole
引脚数 8
封装 PDIP-8
宽度 6.35 mm
封装 PDIP-8
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
OPA2107APG4 TI 德州仪器 | 当前型号 | 当前型号 |
OPA2107AP 德州仪器 | 完全替代 | OPA2107APG4和OPA2107AP的区别 |
