OPA4354AIPWRG4

250MHz轨至轨I / O， CMOS运算放大器 250MHz, Rail-to-Rail I/O, CMOS OPERATIONAL AMPLIFIERS

DESCRIPON

The OPA354 series of high-speed, voltage-feedback CMOS operational amplifiers are designed for video and other applications requiring wide bandwidth. They are unity-gain stable and can drive large output currents. Differential gain is 0.02% and differential phase is 0.09°. Quiescent current is only 4.9mA per channel.

FEATURES

UNITY-GAIN BANDWIDTH: 250MHz

WIDE BANDWIDTH: 100MHz GBW

HIGH SLEW RATE: 150V/µs

LOW NOISE: 6.5nV/√Hz

RAIL-TO-RAIL I/O

HIGH OUTPUT CURRENT: > 100mA

EXCELLENT VIDEO PERFORMANCE:

   Diff Gain: 0.02%, Diff Phase: 0.09

   0.1dB Gain Flatness: 40MHz

LOW INPUT BIAS CURRENT: 3pA

QUIESCENT CURRENT: 4.9mA

THERMAL SHUTDOWN

SUPPLY RANGE: 2.5V to 5.5V

MicroSIZE AND PowerPAD™ PACKAGES
