TEXAS INSTRUMENTS OPA2132UAE4 运算放大器, 双路, 8 MHz, 2个放大器, 20 V/µs, ± 2.5V 至 ± 18V, SOIC, 8 引脚
The is a FET-input Operational Amplifier provides highs-peed and excellent DC performance. The combination of high slew rate and wide bandwidth provide fast settling time. High performance grades are available in the single and dual versions. All are ideal for general-purpose, audio, data acquisition and communications applications, especially where high source impedance is encountered. The OPA2132 is easy to use and free from phase inversion and overload problems often found in common FET-input operational amplifier. Input cascode circuitry provides excellent common-mode rejection and maintains low input bias current over its wide input voltage range. The operational amplifier is stable in unity gain and provides excellent dynamic behaviour over a wide range of load conditions, including high load capacitance. Dual and quad versions feature completely independent circuitry for lowest crosstalk and freedom from interaction, even when overdriven or overloaded.
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
电源电压DC 15.0 V
供电电流 4 mA
电路数 2
通道数 2
针脚数 8
共模抑制比 86 dB
输入补偿漂移 2.00 µV/K
带宽 8 MHz
转换速率 20.0 V/μs
增益频宽积 8 MHz
输入补偿电压 500 µV
输入偏置电流 5 pA
工作温度Max 125 ℃
工作温度Min -40 ℃
增益带宽 8 MHz
共模抑制比Min 86 dB
电源电压Max 18 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
宽度 3.91 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
OPA2132UAE4 TI 德州仪器 | 当前型号 | 当前型号 |
OPA2132UA/2K5E4 德州仪器 | 完全替代 | OPA2132UAE4和OPA2132UA/2K5E4的区别 |
OPA2132UA 德州仪器 | 类似代替 | OPA2132UAE4和OPA2132UA的区别 |
