OPA2613IDTJRG3

高速运算放大器 Dual Wideband Hi-Output Current

DESCRIPON

The OPA2613 offers very low 1.8nV√Hzinput noise in a wideband, unity-gain stable, voltage-feedback architecture. Intended for xDSL driver applications, the OPA2613 also supports this low input noise with exceptionally low harmonic distortion, particularly in differential configurations. Adequate output current is provided to drive the potentially heavy load of a twisted-pair line. Harmonic distortion for a 2VPP differential output operating from +5V to +12V supplies is ≤−95dBc through 1MHz input frequencies. Operating on a low 6.0mA/ch supply current, the OPA2613 can satisfy most xDSL driver requirements over a wide range of possible supply voltage from a single +5 condition, to ±5V, on up to a single +12V design.

FEATURES

LOW INPUT NOISE VOLTAGE: 1.8nV/√Hz

HIGH UNITY-GAIN BANDWIDTH: 230MHz

HIGH GAIN BANDWIDTH PRODUCT: 125MHz

HIGH OUTPUT CURRENT: 350mA

LOW INPUT OFFSET VOLTAGE: ±0.2mV

FLEXIBLE SUPPLY RANGE:

   Single +5V to +12V Operation

   Dual ±2.5V to ±6V Operation

LOW SUPPLY CURRENT: 6.0mA/ch
