OP196GSZ-REEL

OP Amp Single GP R-R I/O 12V 8Pin SOIC N T/R

Product Details

The OP196 family of CBCMOS operational amplifiers features micropower operation and rail-to-rail input and output ranges.

The extremely low power requirements and guaranteed operation from +3 V to +12 V make these amplifiers perfectly suited to monitor battery usage and to control battery charging. Their dynamic performance, including 26 nV/√Hz voltage noise density, recommends them for battery-powered audio applications. Capacitive loads to 200 pF are handled without oscillation.

The OP196/OP296/OP496 are specified over the extended industrial -40°C to +125°C temperature range. +3 V operation is specified over the 0°C to +125°C temperature range.

The single OP196 and the dual OP296 are available in 8-lead SOIC and TSSOP packages. The quad OP496 is available in 14-lead SOIC and TSSOP packages.

### Features and Benefits

.

Rail-to-Rail Input and Output Swing

.

Low Power: 60 µA/Amplifier

.

Gain Bandwidth Product: 450 kHz

.

Single-Supply Operation: 3 V to 12 V

.

Low Offset Voltage: 300 µV max

.

High Open-Loop Gain: 500 V/mV

.

Unity-Gain Stable

.

No Phase Reversal
