OP193FS-REEL7

高精度，微功耗运算放大器 Precision, Micropower Operational Amplifiers

GENERAL DESCRIPTION

The OP193/OP293 are single-supply operational amplifiers that feature a combination of high precision, low supply current, and the ability to operate at low voltages. For high performance in single-supply systems, the input and output ranges include ground, and the outputs swing from the negative rail to within 600 mV of the positive supply. For low voltage operation, the OP193/OP293 can operate down to +1.7 V or ±0.85 V.

FEATURES

Operates from +1.7 V to ±18 V

Low supply current: 15 µA/amplifier

Low offset voltage: 100 µV maximum

Outputs sink and source: ±8 mA

No phase reversal

Single- or dual-supply operation

High open-loop gain: 600 V/mV

Unity-gain stable

APPLICATIONS

Digital scales

Strain gages

Portable medical equipment

Battery-powered instrumentation

Temperature transducer amplifier
