低噪声，低漂移，单电源运算放大器 Low Noise, Low Drift Single-Supply Operational Amplifiers
GENERAL DESCRIPTION
The OPx13 family of single-supply operational amplifiers features both low noise and drift. It has been designed for systems with internal calibration. Often these processor-based systems are capable of calibrating corrections for offset and gain, but they cannot correct for temperature drifts and noise.
FEATURES
Single- or dual-supply operation
Low noise: 4.7 nV/√Hz @ 1 kHz
Wide bandwidth: 3.4 MHz
Low offset voltage: 100 μV
Very low drift: 0.2 μV/°C
Unity gain stable
No phase reversal
APPLICATIONS
Digital scales
Multimedia
Strain gages
Battery-powered instrumentation
Temperature transducer amplifier
供电电流 3 mA
电路数 2
通道数 2
共模抑制比 96.0 dB
转换速率 1.20 V/μs
增益频宽积 3.4 MHz
输入阻抗 42.0 MΩ
输入补偿电压 250 µV
输入偏置电流 240 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 3.4 MHz
共模抑制比Min 90 dB
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 Non-Compliant
含铅标准 Contains Lead
军工级 No
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
OP213FS-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
OP213FSZ 亚德诺 | 类似代替 | OP213FS-REEL7和OP213FSZ的区别 |
OP213FSZ-REEL7 亚德诺 | 类似代替 | OP213FS-REEL7和OP213FSZ-REEL7的区别 |
OP213FSZ-REEL 亚德诺 | 类似代替 | OP213FS-REEL7和OP213FSZ-REEL的区别 |
