Precision Amplifiers 9MHz Prec Dual 5mA 250uV
J-FET 放大器 2 电路 - 8-SOIC
得捷:
IC OPAMP JFET 2 CIRCUIT 8SOIC
立创商城:
OP285GSZ-REEL7
艾睿:
Does your project require any signal processing circuits, control circuits, or instrumentation? Then this general purpose amplifier OP285GSZ-REEL7 OP amp from Analog Devices will ensure you get the most versatility to implement them all! Its typical dual supply voltage is ±5|±9|±12|±15|±18 V, with a minimum of ±4.5 V and maximum of ±22 V. This op amp has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device is made with bifet technology. This device uses dual power supplies. It has 2 channels per chip.
安富利:
OP Amp Dual GP ±22V 8-Pin SOIC N T/R
Verical:
Op Amp Dual High Speed Amplifier ±22V 8-Pin SOIC N T/R
Win Source:
IC OPAMP GP 9MHZ 8SOIC
DeviceMart:
IC OPAMP GP 9MHZ DUAL PREC 8SOIC
供电电流 4 mA
电路数 2
通道数 2
共模抑制比 80 dB
输入电容 7.50 pF
转换速率 22.0 V/μs
增益频宽积 9 MHz
输入补偿电压 35 µV
输入偏置电流 100 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
增益带宽 9 MHz
共模抑制比Min 80 dB
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
OP285GSZ-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
OP285GSZ 亚德诺 | 完全替代 | OP285GSZ-REEL7和OP285GSZ的区别 |
OP285GSZ-REEL 亚德诺 | 完全替代 | OP285GSZ-REEL7和OP285GSZ-REEL的区别 |
OP285GS-REEL7 亚德诺 | 完全替代 | OP285GSZ-REEL7和OP285GS-REEL7的区别 |
