双/四路轨到轨运算放大器 Dual/Quad Rail-to-Rail Operational Amplifiers
GENERAL DESCRIPTION
Rail-to-rail output swing combined with dc accuracy are the key features of the OP495 quad and OP295 dual CBCMOS operational amplifiers. By using a bipolar front end, lower noise and higher accuracy than those of CMOS designs have been achieved. Both input and output ranges include the negative supply, providing the user with zero-in/zero-out capability. For users of 3.3 V systems such as lithium batteries, the OP295/OP495 are specified for 3 V operation.
FEATURES
Rail-to-rail output swing
Single-supply operation: 3 V to 36 V
Low offset voltage: 300 μV
Gain bandwidth product: 75 kHz
High open-loop gain: 1000 V/mV
Unity-gain stable
Low supply current/per amplifier: 150 μA maximum
APPLICATIONS
Battery-operated instrumentation
Servo amplifiers
Actuator drives
Sensor conditioners
Power supply control
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
OP295GS-REEL ADI 亚德诺 | 当前型号 | 当前型号 |
OP295GSZ 亚德诺 | 类似代替 | OP295GS-REEL和OP295GSZ的区别 |
OP295GSZ-REEL7 亚德诺 | 类似代替 | OP295GS-REEL和OP295GSZ-REEL7的区别 |
OP295GSZ-REEL 亚德诺 | 类似代替 | OP295GS-REEL和OP295GSZ-REEL的区别 |
