低噪声、低静态电流精密运算放大器电子微调/交换 8-SOIC -40 to 125
The OPA376-Q1 family represent a new generation of low-noise operational amplifiers with _e-trim_™, offering outstanding dc precision and ac performance. Rail-to-rail output, low offset 25 µV maximum, low noise 7.5 nV/√Hz, quiescent current of 950 µA maximum, and a 5.5-MHz bandwidth make this part very attractive for a variety of precision and portable applications. In addition, this device has a reasonably wide supply range with excellent PSRR, making it attractive for applications that run directly from batteries without regulation.
The OPA376-Q1 single version is available in MicroSIZE SC70-5, SOT23-5, and SOIC-8 packages. The OPA2376-Q1 dual is offered in the SOIC-8 and VSSOP-8 package. The OPA4376-Q1 quad is offered in a TSSOP-14 package. All versions are specified for operation from –40°C to +125°C.
供电电流 760 µA
电路数 2
通道数 2
共模抑制比 76 dB
输入补偿漂移 320 nV/K
转换速率 2.00 V/μs
增益频宽积 5.5 MHz
输入补偿电压 0.025 mV
输入偏置电流 0.0000002μA @5.5V
工作温度Max 125 ℃
工作温度Min -40 ℃
共模抑制比Min 76 dB
电源电压Max 5.5 V
电源电压Min 2.2 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
