OPB350 系列 50 mA 30 V 11.8 mm Range 管式液体传感器
The OPB350 series liquid sensor is designed to work with 1.6 mm, 3.2 mm, 4.8 mm and 6.3 mm outside diameter clear tubes. When output reference circuitry is added, multiple output states such as fluid present, no fluid present and no tube present can be recognized.
得捷:
SENSOR OPT SLOT PHOTOTRAN PCB MT
立创商城:
OPB350L062
艾睿:
Photointerrupter Transmissive Phototransistor 4-Pin Tube
Allied Electronics:
Sensor; Transmissive; Fluid In-Line; 0.062in Tubing; 30V; 890nm; 50 mA
Chip1Stop:
Photointerrupter Transmissive Phototransistor 4-Pin Tube
额定电压DC 30.0 V
通道数 1
正向电压 1.7 V
波长 890 nm
峰值波长 890 nm
耗散功率 100 mW
击穿电压集电极-发射极 30 V
正向电流 50 mA
正向电流Max 50 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 100 mW
安装方式 Through Hole
引脚数 4
封装 BULK
长度 15.88 mm
宽度 7.62 mm
高度 13.34 mm
封装 BULK
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
