LED电源 33.25W 350mA 57-95V CC Dimming Aux DCout
350mA 57 ~ 95V 恒定电流 LED 驱动器 AC DC 转换器 拓扑 1 输出
得捷:
LED DRVR CC AC/DC 57-95V 350MA
贸泽:
LED电源 33.25W 350mA 57-95V CC Dimming Aux DCout
艾睿:
AC/DC LED Power Supply 33.25W Single 8-Pin
TME:
Pwr sup.unit: switched-mode; LED; 33.25W; 57÷95VDC; 350mA; IP67
MASTER:
AC/DC LED Power Supply - Const Curr - 33.25W - Fixed: 118 Vdc OC @ 350mA - Dim: 0-10 Vdc/PWM
Electro Sonic:
AC/DC LED Power Supply - Const Curr - 33.25W - Fixed: 118 Vdc OC @ 350mA - Dim: 0-10 Vdc/PWM
CDI:
LED Driver CC 33.3W 350mA Linear 57-95 90-295Vac PFC PWM, 0-10V Dimming Plastic Enclosure with Aux 12VDC output
额定功率 33 W
输出接口数 1
输出电压 57.0VDC ~ 95.0VDC
输出功率 33.25 W
隔离电压 3.75 kV
输入电压Max 295 VAC
输入电压Min 90 VAC
输出电流Max 350 mA
输出功率Max 33.25 W
工作温度Max 85 ℃
工作温度Min -20 ℃
输入电压 90VAC ~ 295VAC, 127VDC ~ 417VDC
引脚数 8
长度 111 mm
宽度 77 mm
高度 28.5 mm
工作温度 -20℃ ~ 85℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
