PE-0805CM151JTT

0805 150nH ±5% 350mA

150nH Unshielded Wirewound Inductor 350mA 560mOhm Max 0805 2012 Metric

得捷:
FIXED IND 150NH 350MA 560MOHM SM

立创商城:
150nH ±5%

艾睿:
Use this rf chip PE-0805CM151JTT surface mount inductor from Pulse to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 2.29 mm long, 1.58 mm tall and 1.68 mm deep. This device utilizes wirewound technology. It has a tolerance of 5%. It has an inductance of 150n H. This SMD inductor has a maximum DC current of 350m A with a maximum resistance of 560m Ohm. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 900M Hz.

Chip1Stop:
Inductor RF Chip Wirewound 150nH 5% 100MHz 50Q-Factor Ceramic 350mA 560mOhm DCR 0805 T/R

Verical:
Inductor RF Chip Wirewound 0.15uH 5% 100MHz 50Q-Factor Ceramic 0.35A 0.56Ohm DCR 0805 T/R
