Switch Push Button N.O./N.C. DPDT Square Plunger 0.2A 30VDC Alternate Contact PC Pins Thru-Hole Tray
Turn on and off portions of your circuit design with the aid of this push button switch manufactured from C&K Components. It has a DPDT configuration. This device has a maximum current rating of 0.2 A @ 30VDC. This push switch has an operating temperature range of -10 °C to 60 °C. The PN22LESA03QE push switch has a PC pin termination style. This product is 7.2 mm long, 9.8 mm tall and 25 mm deep. The maximum DC voltage rating is 30 VDC.
额定电压DC 30 V
额定电压AC 30 V
额定电流 200mA DC
排数 2
额定功率 0.2 VA
额定电流Max 0.2A @30VDC
工作温度Max 60 ℃
工作温度Min -10 ℃
额定电压DC Max 30 V
接触电阻Max 30 mΩ
安装方式 Through Hole
封装 -
高度 9.8 mm
封装 -
触点材质 Phosphor Bronze
工作温度 -10℃ ~ 60℃
产品生命周期 10000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
PN22LESA03QE C&K Components | 当前型号 | 当前型号 |
PN22LENA03QE C&K Components | 完全替代 | PN22LESA03QE和PN22LENA03QE的区别 |
MDPA822PN Apem Components | 功能相似 | PN22LESA03QE和MDPA822PN的区别 |
