NXP PTN3392BS,518 接口桥接器, 显示端口至VGA, 3 V, 3.6 V, HVQFN, 48 引脚, 0 °C
The is a 2-lane Display Port to VGA Adaptor IC designed to connect a DisplayPort source to a VGA sink. The IC integrates a DisplayPort receiver and a high-speed triple video digital-to-analogue converter that supports display resolutions from VGA to WUXGA. It supports either one or two DisplayPort v1.1a lanes operating at either 2.7 or 1.62G-bit/s per lane. It has flash-over-AUX capability enabling simple firmware upgradability in the field. The PTN3392 supports I²C-bus over AUX per DisplayPort v1.1a specification and bridges the VESA DDC channel to the DisplayPort Interface. Designed for single supply and minimizes application costs. It can be powered directly from the DisplayPort source side 3.3V supply without a need for additional core voltage regulator. The VGA output is powered down when there is no valid DisplayPort source data being transmitted.
电源电压DC 3.00V min
针脚数 48
耗散功率 600 mW
工作温度Max 85 ℃
工作温度Min 0 ℃
电源电压 3V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 48
封装 SOT-619-1
封装 SOT-619-1
工作温度 0℃ ~ 85℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 计算机和计算机周边, 台式,笔记本电脑, Computers & Computer Peripherals
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PTN3392BS,518 NXP 恩智浦 | 当前型号 | 当前型号 |
PTN3392BS/F2,518 恩智浦 | 完全替代 | PTN3392BS,518和PTN3392BS/F2,518的区别 |
PTN3392BS/F3,518 恩智浦 | 完全替代 | PTN3392BS,518和PTN3392BS/F3,518的区别 |
PTN3392BS/F1,518 恩智浦 | 完全替代 | PTN3392BS,518和PTN3392BS/F1,518的区别 |
