PIC16LF723A-I/ML

MICROCHIP  PIC16LF723A-I/ML  微控制器, 8位, 闪存, PIC16LF7xx, 20 MHz, 7 KB, 192 Byte, 28 引脚, QFN

The is a mid-range PIC16 family 8-bit powerful 200 nanosecond instruction execution yet easy-to-program only 35 single word instructions CMOS flash based Microcontroller packs powerful PIC®RISC architecture with XLP technology. This product offer all of the advantages of the well recognized mid-range x14 architecture with standardized features including 7kB of addressable program memory size, 192bytes of data memory size, 25 general-purpose I/O pins and 11-channel 10-bit analog-to-digital A/D converter. This device operates at a maximum frequency of 20MHz with wide operating voltage of 1.8 to 3.6V.

.

35 14-bit wide easy instructions to learn

.

8 level hardware stack

.

1 9-bit file select register

.

Hardware interrupt handling

.

In-Circuit Serial Programming™ ICSP™

.

Power on reset POR

.

Power-up timer PWRT

.

Oscillator start-up timer OST

.

Programmable code protection

.

Power saving SLEEP mode

.

In-circuit debugging via two pins

.

Brown-out reset BOR

.

2x Capture/Compare/PWM ECCP

.

Two 8-bit digital timers

.

One 16-bit digital timers

.

Built-in mTouch™ capacitive sensing module

.

Enhanced power-On/Off-Reset
