PFE500F-48概述
TDK LAMBDA PFE500F-48 电源 交流/直流 电路板安装, 固定/可调, 85 V, 265 V, 504 W, 48 V, 10.5 A
The is a 1-output 504W PCB mount AC/DC Power Module with 38.4 to 57.6V adjustable voltage range. The power supply features overcurrent, overvoltage and overtemperature safety protections.
- .
- Low profile, small size
- .
- High power density
- .
- High efficiency
- .
- Suitable for conduction cooling
- .
- Assists system integration
- .
- Easier to cool
- .
- Power factor corrected PFC
- .
- Supports global use
- .
- Operates in harsh environments
- .
- 100°C baseplate temperature
PFE500F-48中文资料参数规格
技术参数
额定功率 504 W
输出接口数 1
输出电压 48 VDC
输出电流 10.5 A
输出功率 500 W
输入电压AC Max 265 v
输入电压AC Min 85 v
输出功率Max 504 W
输入电压 100VAC, 200VAC
封装参数
封装 Module
外形尺寸
长度 122 mm
宽度 70 mm
高度 12.7 mm
封装 Module
物理参数
重量 300 g
其他
产品生命周期 Active
制造应用 Power Management, Industrial, Test & Measurement, LED Lighting, Power Management, Industrial, Test & Measurement, LED Lighting
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
