PHE844RF6220MR30L2

KEMET  PHE844RF6220MR30L2  膜电容, PHE844系列, 0.22 µF, ± 20%, X1, 径向引线, 105 °C

The PHE844 series capacitors from Kemet are radial leaded, class X1 metalized polypropylene film EMI suppression capacitors. These capacitors are made of metalized polypropylene film encapsulated with self extinguishing resin in a box of material meeting the requirements of UL94 V-0 standard. It is used as an electromagnetic interference EMI suppression filter in across the line applications requiring X1 safety classification and it is suitable for use in situations where failure of the capacitor would not lead to danger of electric shock.

.

Capacitance values ranges from 0.1µF to 2.2µF

.

Voltage rating is 440VAC at 50/60Hz ENEC, 480VAC at 50/60Hz UL, cUL

.

Lead spacing of 22.5mm to 37.5mm

.

Available in ±10%, ±20% tolerance

.

Operating temperature range from -40˚C to 105˚C

.

ENEC, UL, cUL approved

.

Self healing properties

.

100% screening factory test at 3000VDC
