PCM1704U-K

TEXAS INSTRUMENTS  PCM1704U-K  芯片, 数模转换器, 24位, 96kSPS, 2通道

The is a precision 24-bit Digital-to-analogue Converter with exceptionally high dynamic performance. The ultra-low distortion and excellent low-level signal performance. When used with a digital interpolation filter, the PCM1704U-K supports 8X oversampling at 96kHz. The PCM1704U-K incorporates a BiCMOS sign-magnitude architecture that eliminates glitches and other nonlinearities around bipolar zero. The PCM1704U-K is precision laser-trimmed at the factory to minimize differential linearity and gain errors. In addition to high performance audio systems, the PCM1704U-K is well-suited to waveform synthesis applications requiring very low distortion and noise.

.

16 to 96kHz Sampling frequency fS

.

8x Oversampling at 96kHz

.

20, 24-bit Input audio data word

.

High performance

.

K Grade = 112dB typical dynamic range

.

120dB Typical SNR

.

K Grade = 0.0008% typical THD + N

.

±1.2mA/200ns Fast current output

.

Glitch-free output

.

Pin-programmable data inversion

.

±5V Power supply

IC can be damaged by ESD. We recommend that all ICs be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
