ON SEMICONDUCTOR PCA9306FMUTCG 芯片, 电平转换器, 2输入, UDFN-8
电压电平 转换器 双向 1 电路 2 通道 - 8-UDFN(1.45x1)
得捷:
IC TRNSLTR BIDIRECTIONAL 8UDFN
欧时:
ON Semiconductor PCA9306FMUTCG, 双 电压 电压电平移位器, 三态输出, 0 → 5.5 V电源, 8引脚
立创商城:
PCA9306FMUTCG
贸泽:
Translation - Voltage Levels Dual Bidirectional I2C Bus
e络盟:
芯片, 电平转换器, 2输入, UDFN-8
艾睿:
If you are looking for a device to shift between voltage levels in your microprocessor-based circuit, then the PCA9306FMUTCG level translator from ON Semiconductor is for you. This level shifter has a minimum operating temperature of -55 °C and a maximum of 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 0 V, while its maximum is 5.5 V.
安富利:
Voltage Level Translator 8-Pin UDFN T/R
Verical:
Voltage Level Translator 2-CH Bidirectional 8-Pin UDFN T/R
力源芯城:
双路双向I2C总线和SMBus电压电平转换器
Win Source:
IC TRNSLTR BIDIRECTIONAL 8UDFN / Voltage Level Translator Bidirectional 1 Circuit 2 Channel 8-UDFN 1.45x1
电源电压DC 0.00Vmin, 5.50Vmax
无卤素状态 Halogen Free
输出电流 64 mA
电路数 1
通道数 2
针脚数 8
耗散功率 833 mW
输入数 2
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压Max 5.5 V
电源电压Min 0 V
安装方式 Surface Mount
引脚数 8
封装 UDFN-8
长度 1.45 mm
宽度 1 mm
高度 0.5 mm
封装 UDFN-8
工作温度 -55℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Automotive, Communications & Networking, Tablet, Handset, etc, 车用, 通信与网络
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
