P1011NXN2HFB

NXP  P1011NXN2HFB  芯片, 微处理器, 32位, 800MHZ, TEPBGA-689

Overview

The QorIQ® P1 platform series, which includes the P1020 and P1011 communications processors, offers the value of extensive integration and extreme power for a wide variety of applications in the networking, telecom, aerospace, defense and industrial markets. The series provides dual-and single-core solutions for the 533 MHz to 800 MHz performance range, along with advanced security and a rich set of interfaces delivered on 45 nm technology for a low-power implementation.

The P1 platform series is perfectly suited for multiservice gateways, Ethernet switch controllers, wireless LAN access points and high-performance general-purpose control processor applications with tight thermal constraints.

The QorIQ P1 series consists of dual- and single-core products that are pin-compatible with QorIQ P2 platform products, offering a five-chip range of cost-effective solutions. Scaling from a single core at 533 MHz P1011 to a dual core at 1.2 GHz per core P2020, the two QorIQ platforms deliver an impressive 4.5X aggregate frequency range.

MoreLess

## Features

### Core Complex

* Dual P1020 or single P1011 high-performance Power Architecture® e500 cores, 32 KB L1 cache, up to 800 MHz

* 256 KB L2 cache with ECC, also configurable as SRAM and stashing memory

### Networking Elements

* Three 10/100/1000 Mbps enhanced triple speed Ethernet controllers eTSEC

* Two SGMII interfaces

* Support for IEEE® 1588

### Accelerators and Memory Control

* DDR2/3 32-bit memory controller with ECC support

* Integrated security engine

* Protocol support includes SNOW, ARC4, 3DES, AES, RSA/ECC, RNG, single-pass SSL/TLS, Kasumi

* XOR acceleration

### Basic Peripherals and Interconnect

* Four lane SERDES up to 3.125 GHz multiplexed across controllers

* Two PCI Express® Gen1.0 interface controllers

* Two USB2.0 controllers

* Enhanced Local Bus Controller eLBC

* TDM

* eSDHC

* Dual I²C, DUART, PIC, DMA, GPIO

### Additional Features

* ® Product Longevity Program

* 689-pin 31x31 mm TePBGA package
