Ceramic Resonator 16MHz 0.5% Tol 0.1% Stability 12.5pF Automotive 3Pin CSMD T/R
16 MHz Ceramic Resonator Built in Capacitor 10 pF ±0.1% -40°C ~ 85°C Surface Mount
得捷:
CERAMIC RES 16.0000MHZ 10PF SMD
艾睿:
Ceramic Resonator 16MHz
安富利:
Resonator 16MHz 10pF 3-Pin CSMD T/R
Chip1Stop:
Ceramic Resonator 16MHz ?0.5% Tol ?0.1% Stability 12.5pF Automotive 3-Pin CSMD T/R
Verical:
Ceramic Resonator 16MHz ±0.5% Tol ±0.1% Stability 12.5pF Automotive 3-Pin CSMD T/R
Newark:
# AVX PBRC16.00MR50X000 Resonator, Ceramic, 16 MHz, SMD, 3 Pin, ± 0.1%
频率 16 MHz
频率稳定度 ±0.1 %
频率容差 ±0.7 %
电容 10 pF
容差 0.5 %
负载电容 12.5 pF
共振频率 16.0 MHz
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 3
封装 SMD-3
长度 4.5 mm
宽度 2 mm
封装 SMD-3
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
