28 /40/ 44引脚,低功耗,高性能的微控制器采用nanoWatt XLP技术 28/40/44-Pin, Low-Power, High-Performance Microcontrollers with nanoWatt XLP Technology
PIC PIC® XLP™ 18K Microcontroller IC 8-Bit 48MHz 8KB 4K x 16 FLASH 28-SOIC
得捷:
IC MCU 8BIT 8KB FLASH 28SOIC
立创商城:
PIC 48MHz 闪存:4K@x16bit
艾睿:
With the PIC18F23K22-E/SO microcontroller from Microchip Technology, you can program a circuit to perform tasks that meet your desired specifications. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 125 °C. It has a maximum clock speed of 16 MHz. Its flash program memory is 8KB. This is a 8 bit processor. This device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 1.8 V, while its maximum is 5.5 V. Its ADC resolution is 10. This device is based on the PIC core architecture.
Allied Electronics:
8KB, Flash, 768Bytes-RAM, 8-Bit nanoWattXLP, SOIC-8 .300IN TUBE
安富利:
MCU 8-bit PIC18 PIC RISC 8KB Flash 2.5V/3.3V/5V 28-Pin SOIC W Tube
工作电压 2.3V ~ 5.5V
RAM大小 512 B
位数 8
耗散功率 1000 mW
模数转换数ADC 2
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
电源电压 2.3V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.3 V
安装方式 Surface Mount
引脚数 28
封装 SOIC-28
长度 17.9 mm
宽度 7.5 mm
高度 2.35 mm
封装 SOIC-28
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC18F23K22-E/SO Microchip 微芯 | 当前型号 | 当前型号 |
PIC18F25K22-I/SO 微芯 | 类似代替 | PIC18F23K22-E/SO和PIC18F25K22-I/SO的区别 |
PIC18F23K22-I/SO 微芯 | 类似代替 | PIC18F23K22-E/SO和PIC18F23K22-I/SO的区别 |
PIC18F25K22-E/SO 微芯 | 类似代替 | PIC18F23K22-E/SO和PIC18F25K22-E/SO的区别 |
