20引脚基于闪存的8位CMOS微控制器采用纳瓦技术 20-Pin Flash-Based, 8-Bit CMOS Microcontrollers with nanoWatt Technology
PIC series IC 8 位 20MHz 7KB（4K x 14） 闪存 20-SSOP
立创商城:
PIC 20MHz 闪存：4K@x14bit
得捷:
IC MCU 8BIT 7KB FLASH 20SSOP
贸泽:
8-bit Microcontrollers - MCU 7KB FL 256R 18 I/O
艾睿:
Want to centralize your components to one device? Look no further use this PIC16F690T-E/SS microcontroller manufactured by Microchip Technology. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 125 °C. It has a maximum clock speed of 20 MHz. This is a 8 bit processor. Its ADC resolution is 10. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V. This device is based on the PIC core architecture. Its flash program memory is 7KB.
Allied Electronics:
7 KB Flash; 256 RAM; 18 I/O20 SSOP .209in T/R
安富利:
MCU 8-bit PIC16 PIC RISC 7KB Flash 5V 20-Pin SSOP T/R
儒卓力:
**PIC16F 7K SSOP20 125°C **
电源电压DC 5.00 V, 5.50 V max
时钟频率 20.0MHz max
RAM大小 256 B
位数 8
耗散功率 800 mW
I/O引脚数 18
存取时间 20.0 µs
内核架构 PIC
内核子架构 PIC16
模数转换数ADC 1
工作温度Max 125 ℃
工作温度Min 40 ℃
耗散功率Max 800 mW
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 SSOP-20
长度 7.2 mm
宽度 5.3 mm
高度 1.75 mm
封装 SSOP-20
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
PIC16F690T-E/SS Microchip 微芯 | 当前型号 | 当前型号 |
PIC16F690T-E/ML 微芯 | 完全替代 | PIC16F690T-E/SS和PIC16F690T-E/ML的区别 |
PIC16F690-I/P 微芯 | 类似代替 | PIC16F690T-E/SS和PIC16F690-I/P的区别 |
PIC16F690-I/SS 微芯 | 类似代替 | PIC16F690T-E/SS和PIC16F690-I/SS的区别 |
