TEXAS INSTRUMENTS PGA2320IDW 音频控制器, 音量, 4.5V 至 5.5V, ± 4.5V 至 ± 15.5V, 串行, SOIC, 16 引脚, -40 °C
音频数字电位计,Texas Instruments
Texas Instruments 的数字电位计、衰减器和音量控制器,用于音频应用。
得捷:
IC VOLUME CONTROL 16SOIC
欧时:
### 音频数字电位计,Texas InstrumentsTexas Instruments 的数字电位计、衰减器和音量控制器,用于音频应用。### 数字电位计 - Texas Instruments
立创商城:
PGA2320IDW
德州仪器TI:
+/-15-V stereo audio volume control with low gain error 0.1
贸泽:
音频放大器 .+/-15V Stereo Audio Volume Control
e络盟:
音频控制器, 音量, 4.5V 至 5.5V, ± 4.5V 至 ± 15.5V, 串行, SOIC, 16 引脚, -40 °C
艾睿:
Audio Amp Speaker 1-CH Mono Class-AB Automotive 16-Pin SOIC Tube
安富利:
The PGA2320 is a high-performance, stereo audio volume control designed for professional and high-end consumer audio systems. The ability to operate from ±15V analog power supplies enables the PGA2320 to process input signals with large voltage swings, thereby preserving the dynamic range available in the overall signal path. Using high performance operational amplifier stages internal to the PGA2320 yields low noise and distortion, while providing the capability to drive 600Ω loads directly without buffering. The three-wire serial control interface allows for connection to a wide variety of host controllers, in addition to support for daisy-chaining of multiple PGA2320 devices.
Chip1Stop:
Stereo Audio Volume Control 16-Pin SOIC Tube
TME:
Integrated circuit: audio mixer; serial; SO16
Verical:
Audio Amp Speaker 1-CH Mono Class-AB Automotive 16-Pin SOIC Tube
Newark:
# TEXAS INSTRUMENTS PGA2320IDW Audio Control, Volume, ± 4.5V to ± 15V, Serial, SOIC, 16 Pins, -40 °C
DeviceMart:
IC STEREO AUDIO VOL CTRL 16-SOIC
电源电压DC 5.00 V
通道数 2
针脚数 16
静态电流 11.0 mA
增益频宽积 1 MHz
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 16
封装 SOIC-16
长度 10.28 mm
宽度 7.52 mm
高度 2.35 mm
封装 SOIC-16
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tube
制造应用 车用, 汽车音频,乐器,专业音频设备, 通信与网络, 成像, 视频和目视, 消费电子产品, 信号处理, 音频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PGA2320IDW TI 德州仪器 | 当前型号 | 当前型号 |
PGA2320IDWG4 德州仪器 | 完全替代 | PGA2320IDW和PGA2320IDWG4的区别 |
PGA2320IDWR 德州仪器 | 完全替代 | PGA2320IDW和PGA2320IDWR的区别 |
PGA2320IDWRG4 德州仪器 | 完全替代 | PGA2320IDW和PGA2320IDWRG4的区别 |
