EPROM /基于ROM的8位CMOS微控制器系列 EPROM/ROM-Based 8-Bit CMOS Microcontroller Series
PIC series IC 8 位 4MHz 768B(512 x 12) OTP 18-SOIC
得捷:
IC MCU 8BIT 768B OTP 18SOIC
立创商城:
PIC16C54-XTI/SO
贸泽:
8-bit Microcontrollers - MCU .75KB 25 RAM 12 I/O SC/R IndTemp SOIC18
艾睿:
This PIC16C54-XTI/SO microcontroller from Microchip Technology is perfect for users that want a fast CPU. This microcontroller has an operating temperature range of -40 °C to 85 °C. It has a maximum clock speed of 4 MHz. This device is based on the PIC core architecture. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3 V, while its maximum is 6.25 V. This is a 8 bit processor. Its eprom program memory is 512B.
安富利:
MCU 8-bit PIC16 PIC RISC 512byte EPROM 3.3V/5V 18-Pin SOIC W Tube
罗切斯特:
MCU 8-bit PIC16 PIC RISC 512B EPROM 3.3V/5V Automotive 18-Pin SOIC W Tube
DeviceMart:
IC MCU OTP 512X12 18SOIC
Win Source:
EPROM/ROM-Based 8-Bit CMOS Microcontroller Series
电源电压DC 5.00 V, 6.25 V max
时钟频率 4.00 MHz, 4.00 MHz max
RAM大小 25 x 8
耗散功率 800 mW
I/O引脚数 12
存取时间 4.00 µs
内核架构 PIC
工作温度Max 85 ℃
工作温度Min 40 ℃
耗散功率Max 800 mW
电源电压Max 6.25 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 18
封装 SOIC-18
长度 11.53 mm
宽度 7.49 mm
高度 2.31 mm
封装 SOIC-18
工作温度 -40℃ ~ 85℃
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC16C54-XTI/SO Microchip 微芯 | 当前型号 | 当前型号 |
PIC16F54-I/SO 微芯 | 类似代替 | PIC16C54-XTI/SO和PIC16F54-I/SO的区别 |
PIC16C54-XT/P 微芯 | 类似代替 | PIC16C54-XTI/SO和PIC16C54-XT/P的区别 |
PIC16C54-XT/SO 微芯 | 类似代替 | PIC16C54-XTI/SO和PIC16C54-XT/SO的区别 |
