PIC18F2480/2580/4480/4580 8 位闪存微控制器### PIC18 微控制器
PIC18F2480/2580/4480/4580 8 位闪存
得捷:
IC MCU 8BIT 16KB FLASH 44TQFP
欧时:
Microchip PIC18F 系列 MCU 8 bit PIC PIC18F4480-E/PT, 40MHz, 16 kB,256 B ROM 闪存, 768 B RAM, TQFP-44
立创商城:
PIC18F4480-E/PT
艾睿:
Need a strong device that can control other devices in your circuit design? Look no further. This PIC18F4480-E/PT microcontroller manufactured by Microchip Technology will meet and excel your needs. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 125 °C. It has a maximum clock speed of 40 MHz. Its ADC resolution is 10. This device is based on the PIC core architecture. This is a 8 bit processor. Its flash program memory is 16KB. This device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.2 V, while its maximum is 5.5 V.
Allied Electronics:
PIC18F4480-E/PT, 8bit PIC Microcontroller, 40MHz, 16kb, 256 B Flash, 44-Pin TQFP
安富利:
MCU 8-bit PIC18 PIC RISC 16KB Flash 2.5V/3.3V/5V 44-Pin TQFP Tray
电源电压DC 5.00 V, 5.50 V max
时钟频率 40.0MHz max
RAM大小 768 B
位数 8
耗散功率 1000 mW
I/O引脚数 25
存取时间 40.0 µs
内核架构 PIC
模数转换数ADC 1
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
安装方式 Surface Mount
引脚数 44
封装 TQFP-44
长度 10 mm
宽度 10 mm
高度 1.05 mm
封装 TQFP-44
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
PIC18F4480-E/PT Microchip 微芯 | 当前型号 | 当前型号 |
PIC18F448-E/PT 微芯 | 类似代替 | PIC18F4480-E/PT和PIC18F448-E/PT的区别 |
