P6KE39CA-E3/73

ESD 抑制器/TVS 二极管 600W 39V Bidirect

53.9V Clamp 11.1A Ipp Tvs Diode Through Hole DO-204AC DO-15

得捷:
TVS DIODE 33.3V 53.9V DO204AC

贸泽:
ESD 抑制器/TVS 二极管 600W 39V Bidirect

艾睿:
Diode TVS Single Bi-Dir 33.3V 600W 2-Pin DO-15 Ammo

安富利:
* Glass passivated chip junction * Available in uni-directional and bi-directional * 600 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate duty cycle: 0.01 % * Excellent clamping capability * Very fast response time * Low incremental surge resistance * Solder dip 275°C max. 10 s, per JESD 22-B106 * AEC-Q101 qualified * Breakdown voltage 41V Max * Peak Pulse Current 11.1A
