PE-54039SNLT

150KHz National Semiconductor Simple Switcher 线绕扼流圈脉冲环形电感器设计用于与 National Semiconductors 150kHz Simple Switcher™ 一起使用。 这些环形电感器的基座材料符合 UL 94V-0 易燃性要求，且其性能经过 National Semiconductor 认证。

150KHz National Semiconductor Simple Switcher 线绕扼流圈

脉冲环形器设计用于与 National Semiconductors 150kHz Simple Switcher™ 一起使用。 这些环形电感器的基座材料符合 UL 94V-0 易燃性要求，且其性能经过 National Semiconductor 认证。

得捷:
FIXED IND 53UH 3A 80 MOHM SMD

立创商城:
53uH ±20% 3A 80mΩ

欧时:
Pulse 屏蔽 53 μH 绕线贴片电感器 PE-54039SNLT, ±20%容差, 3A Idc, 80mΩ最大直流电阻, HCI-68封装

贸泽:
Fixed Inductors SIMPLE SWITCHER INDUCTOR

艾睿:
An ideal space-saving electronic component is this power PE-54039SNLT surface mount inductor from Pulse. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 130 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a tolerance of 20%. This product is 23.87 mm long, 10.16 mm tall and 23.87 mm deep. This SMD inductor has a maximum DC current of 3 A with a maximum resistance of 80mTyp Ohm. It has an inductance of 53u H. This device is made with wirewound technology.

安富利:
Ind Power Wirewound 53uH 20% 3A T/R

Verical:
Inductor Power Toroid 53uH 20% 3A 0.08Ohm DCR T/R

儒卓力:
**PE-54039S SMD 53uH 3000mA 150kH **

CDI:
SIMPLE SWITCHER INDUCTOR, NL
