Cap Aluminum Polymer 56uF 20VDC 20% 6.3 X 6mm SMD 0.048Ω 1300mA 3000H 105℃ Automotive T/R
56 µF 20 V 铝聚合物器 径向,Can - SMD 48 毫欧 105°C 时为 3000 小时
立创商城:
56uF ±20% 20V
得捷:
CAP ALUM POLY 56UF 20% 20V SMD
艾睿:
Using one of Nichicon&s;s PCV1D560MCL2GS conductive polymer aluminum solid capacitors, you can be sure that any excess voltages entering your integrated circuits are properly absorbed. It can withstand a voltage of 20 VDC. It has 2 terminals. It has a tolerance of 20%. This product is 6 mm tall with a diameter of 6.3 mm. This conductive polymer aluminum solid capacitor has a minimum operating temperature of -55 °C and a maximum of 105 °C. Its leakage current is 224@2Min μA.
Allied Electronics:
Capacitor; Aluminum Organic; Cap 56 uF; Tol 20%; Vol-Rtg 20 VDC; SMT; 6.3x6 mm
安富利:
Cap Aluminum 56uF 20V 20% 6.3 X 6mm Cylindrical 0.048 Ohm 1300mA 3000 hr 105°C T/R
Verical:
Cap Aluminum Polymer 56uF 20VDC 20% 6.3 X 6mm SMD 0.048 Ohm 1300mA 3000h 105C Automotive T/R
额定电压DC 20.0 V
电容 56 µF
等效串联电阻ESR 48 mΩ
容差 ±20 %
纹波电流 1.3 A
纹波电流低频 1.3A @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 20 VDC
安装方式 Surface Mount
封装 SMD
高度 6 mm
直径 6.30 mm
封装 SMD
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
寿命(小时) 3000 h
制造应用 通用, -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
