铝有机聚合物电容器 2.5volts 1500uF SMD Low ESR
Feel rest assured that "s conductive polymer aluminum solid capacitors can help regulate any voltage spikes or drops that may harm sensitive circuitry. It can withstand a voltage of 2.5 VDC. It has 2 terminals. This product is 12 mm tall with a diameter of 8 mm. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C. Its leakage current is 750@2Min μA. It has a tolerance of 20%.
额定电压DC 2.50 V
电容 1500 µF
等效串联电阻ESR 9 mΩ
容差 ±20 %
纹波电流 5400 mA
纹波电流低频 4.8A @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 2.5 V
安装方式 Surface Mount
封装 SMD
长度 12 mm
高度 12 mm
直径 8.00 mm
封装 SMD
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
寿命（小时） 2000h @105℃
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
PCJ0E152MCL1GS Nichicon 尼吉康 | 当前型号 | 当前型号 |
PCJ0G152MCL4GS 尼吉康 | 功能相似 | PCJ0E152MCL1GS和PCJ0G152MCL4GS的区别 |
RHS0E152MCN1GS 尼吉康 | 功能相似 | PCJ0E152MCL1GS和RHS0E152MCN1GS的区别 |
