Cap Aluminum Polymer 22uF 35VDC 20% 6.3 X 6mm SMD Radial 0.05Ω 1300mA 3000H 105℃ Automotive T/R
铝聚合物器 径向,Can - SMD 50 毫欧 105°C 时为 3000 小时
得捷:
CAP ALUM POLY 22UF 20% 35V SMD
立创商城:
22uF ±20% 35V
贸泽:
Aluminum Organic Polymer Capacitors 35V 22uF 105C
艾睿:
Using one of Nichicon&s;s PCV1V220MCL2GS conductive polymer aluminum solid capacitors, you can be sure that any excess voltages entering your integrated circuits are properly absorbed. It can withstand a voltage of 35 VDC. It has 2 terminals. This product is 6 mm tall with a diameter of 6.3 mm. It has a tolerance of 20%. This conductive polymer aluminum solid capacitor has a minimum operating temperature of -55 °C and a maximum of 105 °C. The PCV1V220MCL2GS conductive polymer aluminum solid capacitor has a radial termination style. Its leakage current is 154@2Min μA.
Allied Electronics:
Capacitor; Aluminum Organic; Cap 22 uF; Tol 20%; Vol-Rtg 35 VDC; SMT; 6.3x6 mm
安富利:
Cap Aluminum 22uF 35V 20% 6.3 X 6mm Cylindrical 0.05 Ohm 1300mA 3000 hr 105°C T/R
Verical:
Cap Aluminum Polymer 22uF 35VDC 20% 6.3 X 6mm SMD Radial 0.05 Ohm 1300mA 3000h 105C Automotive T/R
额定电压DC 35 V
电容 22 µF
等效串联电阻ESR 50 mΩ
容差 ±20 %
纹波电流 1300 mA
纹波电流低频 1.3A @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 35 VDC
安装方式 Surface Mount
引脚数 2
封装 Radial, CAN
长度 6 mm
高度 6 mm
直径 6.3 mm
封装 Radial, CAN
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
寿命(小时) 3000 h
制造应用 -, 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
