PCX1C391MCL1GS

NICHICON  PCX1C391MCL1GS  铝电解电容, 390uF, 16V, SMD

CX 系列

CX 系列铝电解器是高可靠性聚合物电容器，额定寿命长达 2000 小时。 CX 系列电容器提供高温度范围、高电压、低 ESR 和高波纹电流。 CX 系列设计使其适用于以下应用，包括主板和汽车娱乐系统。

高可靠性

低等效串联电阻

高波纹电流

长寿命，长达 3000 小时

无铅回流焊接

立创商城:
390uF ±20% 16V

欧时:
Nichicon 铝聚合物电容器 CX 系列 16V dc 390μF 表面安装器件 聚合体 PCX1C391MCL1GS, ±20%容差

贸泽:
Aluminum Organic Polymer Capacitors 16V 390uF 20%

艾睿:
Look no further than the PCX1C391MCL1GS conductive polymer aluminum solid capacitor from Nichicon, ideal for use in supporting changes in the load of an integrated circuit. It can withstand a voltage of 16 VDC. It has 2 terminals. This product is 12.7 mm tall with a diameter of 10 mm. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 125 °C. It has a tolerance of 20%. Its leakage current is 1248@2Min μA.

Allied Electronics:
390uF 16V Polymer ALUM Electrolytic Cap5101-1, CX Series 3000h 10Dia.x12.6mm

安富利:
Cap Aluminum 390uF 16V 20% 10 X 12.7mm SMD 0.026 Ohm 2700mA 3000 hr 125°C T/R

Verical:
Cap Aluminum Polymer 390uF 16VDC 20% 10 X 12.7mm SMD 0.026 Ohm 2700mA 3000h 125C Automotive T/R

Newark:
# NICHICON  PCX1C391MCL1GS  Electrolytic Capacitor, SP-Cap, 390 µF, 16 V, CX Series, Radial Can - SMD, -55 °C
