PCX1D121MCL6GS

NICHICON  PCX1D121MCL6GS  铝电解电容, 120uF, 20V, SMD

**Features:

**

* Capacitance Range: 5.6 to 390 μF

* Voltage Range: 16 to 50 VDC

* Tolerance: 20% at 120 Hz, 20°C

* Temperature Range: –55 to +125°C

* High Reliability, High Voltage to 50 VDC

* Low ESR, High Ripple Current

* Long Life of 1500 to 3000 Hours at 125°C

* SMD Type: Lead Free Reflow Soldering Condition at 260°C Peak Complete Correspondence

立创商城:
120uF ±20% 20V

得捷:
CAP ALUM POLY 120UF 20% 20V SMD

e络盟:
铝电解电容, 120uF, 20V, SMD

艾睿:
Cap Aluminum Polymer 120uF 20VDC 20% 8 X 10mm SMD 0.029 Ohm 1900mA 3000h 125°C Automotive T/R

Allied Electronics:
120uF 20 V Polymer Aluminium Electrolytic Capacitor; CX Series 3000h 8 x 10mm

Verical:
Cap Aluminum Polymer 120uF 20VDC 20% 8 X 10mm SMD 0.029 Ohm 1900mA 3000h 125C Automotive T/R

Newark:
# NICHICON  PCX1D121MCL6GS  Electrolytic Capacitor, SP-Cap, 120 µF, 20 V, CX Series, Radial Can - SMD, -55 °C
