PCR 系列 16 V 680 uF 10 x 10 mm 表面贴装 铝 电解 电容
**Features:
**
* Capacitance Range: 5.6 to 2700 μF
* Voltage Range: 6.3 to 100 VDC
* Tolerance: 20% at 120 Hz, 20°C
* Temperature Range: –55 to +125°C
* High Reliability, High Voltage to 100 V
* Low ESR, High Ripple Current
* Long Life of 4000 Hours at 125°C
* SMD Type : Lead Free Reflow Soldering Condition at 260°C Peak Complete Correspondence
* Added ESR Specification After the Test at –40°C
欧时:
Capacitor SMD CAP 16 680uF 20%
立创商城:
680uF ±20% 16V
贸泽:
铝有机聚合物电容器 16V 680uF 20%
艾睿:
Cap Aluminum Polymer 680uF 16VDC 20% 10 X 10mm SMD 0.038 Ohm 3200mA 4000h 125°C Automotive T/R
Allied Electronics:
680uF 16V Polymer ALUM Electrolytic Capacitor, CR Series 4000h 10.3x10.3x9.9mm
安富利:
Cap Aluminum 680uF 16V 20% 10 X 10mm Cylindrical 0.019 Ohm 3200mA 4000 hr 125°C T/R
