Module DC-DC 48Vin 1Out 5V 6A 30W 19Pin SIP Module Tray
Isolated Module DC DC Converter 1 Output 5V 6A 36V - 75V Input
得捷:
DC DC CONVERTER 5V 30W
艾睿:
Provide the ability to switch between voltages by using this step down PT3322C DC to DC converter and switching regulator module. It has a voltage of 5 V. This part has a temperature range of -40 °C to 85 °C. The component will be shipped in tray format.
Verical:
Module DC-DC 48VIN 1-OUT 5V 6A 30W 19-Pin SIP SMD Module Tray
额定功率 30 W
输出接口数 1
输出电压 5 V
输出电流 6 A
输出功率 30 W
隔离电压 1.5 kV
输入电压Max 75 V
输入电压Min 36 V
输出电流Max 6 A
额定功率Max 30 W
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 36V ~ 75V
安装方式 Surface Mount
引脚数 19
封装 SMD-19
长度 77.0 mm
宽度 32.5 mm
高度 12.7 mm
封装 SMD-19
工作温度 -40℃ ~ 85℃
产品生命周期 Obsolete
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
