Module DC-DC 24Vin 1Out 12V 2.5A 30W 6Pin
PXE Series 20-30W Single and Dual Output DC-DC Converters
**Features:**
* Industry Standard 2" x 1.6" Footprint
* Six Sided Shielding
* Agency Approved
* 12V, 24V and 48V Inputs
* UL, CSA, EN, CE approvals
* Wide range input
得捷:
DC DC CONVERTER 12V 30W
贸泽:
Isolated DC/DC Converters 30W 12V 2.5A
艾睿:
Provide the ability to switch between voltages by using this step down PXE3024WS12 DC to DC converter and switching regulator module. It has a voltage of 12 V. This part has a minimum operating temperature of -40 °C and a maximum of 100 °C.
Allied Electronics:
Power Supply; 30W30W1040VDC12V@2.5A
额定功率 30 W
输出接口数 1
输出电压 12 VDC
输出电流 2.5 A
输出功率 30 W
隔离电压 1.6 kV
输入电压Max 40 V
输入电压Min 10 V
输出电流Max 2.5 A
工作温度Max 100 ℃
工作温度Min -40 ℃
输入电压 10V ~ 40V
安装方式 Through Hole
引脚数 6
封装 DIP-8
长度 2 in
宽度 1.6 in
高度 0.4 in
封装 DIP-8
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE(商业)
RoHS标准 RoHS Compliant
含铅标准 Lead Free
