LED Uni-Color Yellow Green 570nm 2Pin SMD T/R
绿色 572nm 指示 - 分立 2.1V 2-SMD,无引线
得捷:
LED GREEN CLEAR SMD R/A
艾睿:
LED Uni-Color Yellow Green 570nm 2-Pin SMD T/R
Chip1Stop:
LED Uni-Color Yellow Green 570nm 2-Pin SMD T/R
Verical:
LED Uni-Color Yellow Green 570nm 2-Pin SMD T/R
AMEYA360:
LED YELLOW-GREEN CLR RT ANG SMD
Win Source:
Green 572nm LED Indication - Discrete 2.1V 2-SMD, No Lead
正向电压 2.1 V
波长 572 nm
发光强度 8.8 mcd
视角 131°, 120°
透镜样式 Non-Diffused
峰值波长 570 nm
耗散功率 70 W
测试电流 20 mA
正向电流 25 mA
正向电压Max 2.8 V
正向电流Max 25 mA
工作温度Max 85 ℃
工作温度Min -30 ℃
耗散功率Max 70 mW
安装方式 Surface Mount
引脚数 2
封装 SMD-2
长度 3.00 mm
宽度 1.00 mm
高度 1.00 mm
封装 SMD-2
颜色 Green
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
