Var MOV 150VAC/200VDC 400A 240V 3225 SMD T/R
A nonlinear resistor this MOV manufactured from SEI will change resistance. Its maximum surge current is 400 A. This device"s clamping current is 5 A and clamping voltage is 395 V. This voltage dependent resistor has an operating temperature of -40 to 85 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. Its capacitance value is 140pF. This product is 8 mm long, 3.4 mm tall and 6.3 mm deep. This varistor has a voltage of 240 V. This device is made with metal oxide technology. Its tolerance voltage is 10%. The maximum AC voltage rating is 150 VAC and the maximum DC voltage rating is 200 VDC.
